Using the molding process, the fluorine material and the valve body are tightly bonded. Valve stem packing automatic compensation design, the seat adopts linear sealing, sealing effect is good.
Suitable for petroleum, chemical industry, electronics, metallurgy, medicine, electric power, environmental protection and other industrial sectors, can achieve acid, alkali and other strong corrosive media flow and cut off.
Short Description
Standards
- Connection flange: ISOPN10/16, DIN PN10/16/25, ANSI B16.1
- Driving flange: ISO 5211
- Test standard: API 598
- Design standard: API 608
Material
- Valve body: WCB+F46/PFA, CF8 +F46/PFA, CF8M +F46/PFA
- Ball body: WCB+F46/PFA, CF8 +F46/PFA, CF8M +F46/PFA
- Valve seat: PTFE, RPTFE, PPL
Technical Parameter
- Pressure range: PN16-25(Class150-Class300)
- Valve size: DN15-300
- Connection mode: FlangeTypeWeldinType
- Temperature range: -29℃-150℃
- Actuator: Handle, Worm gear, Pneumatic, Electric, Hydraulic
